BBM Board & Batten

Sturdy board & batten – available HD finishes.

BBM Board & Batten
Request Pricing

Innovative Slide & Tuck Construction

BBM Board & Batten is a modern steel wall panel. Hidden fastened technology and refined flashing details converge for an incredible siding experience.

Bbm Board And Batten Product Bbm Bnb P001 Panel Side Angle
Bbm Board And Batten Product Bbm Bnb P002 Panel Overhead
Bbm Board And Batten Product Bbm Bnb P003 Panel Front Angle
Bbm Board And Batten Product Bbm Bnb P004 Assembly Side Angle
Bbm Board And Batten Product Bbm Bnb P005 Assembly Overhead
Bbm Board And Batten Product Bbm Bnb P006 Assembly Front Angle

Design & Size

We provide BBM Board & Batten custom cut to the inch per specifications. Any length is available from 3′ up to 20′. Panels can be installed horizontally or vertically. BBM Board & Batten’s design features 12″ coverage panels with 2-2/3″ wide x 1″ high battens. Thickness options include 29 and 26 gauge as standard and 24 and 22 gauge as optional.


12" Width (Coverage)
Cut to Inch From 3'-20'

Gauge & Weight

29 Gauge - 0.77 Lb / Sq Ft
26 Gauge - 1.00 Lb / Sq Ft
24 Gauge - 1.25 Lb / Sq Ft
22 Gauge - 1.94 Lb / Sq Ft

Warranty & Finish

Painted BBM Board & Batten carries a 40 year paint warranty and 30 year fade/chalk warranty. Unpainted Galvalume carries a 25 year warranty. The painted option is a baked on enamel paint over primer and Galvalume. The non-painted Galvalume option is 45% zinc and 55% aluminum with a clear acrylic overcoat.

Finish & Warranty

Painted: 40 Years
Galvalume: 25 Years



Purpose & Use

BBM Board & Batten is a durable steel wall panel system. Hidden fasteners and a versatile clip design ensure a permanent and strong system.

BBM Board & Batten should be installed over solid decking. Common uses include both residential and light commercial application.

Minimum Slope



Solid Deck


Light Commercial

Pure White (26ga)
Stone (26ga)
Sierra Tan (26ga)
Brown (26ga)
Light Gray (26ga)
Charcoal (26ga)
Bronze (26ga)
Black (26ga)
Bright Red (26ga)
Barn Red (26ga)
Burgundy (26ga)
Hawaiian Blue (26ga)
Gallery Blue (26ga)
Forest Green (26ga)
HD Black (26ga Premium)
HD Forest Green (26ga Premium)
HD Charcoal (26ga Premium)
HD Barn Red (26ga Premium)
HD Bronze (26ga Premium)
Copper Penny (26ga Premium)
Galvalume (Non-Painted)
Regal White (24ga)
Bone White (24ga)
Sandstone (24ga)
Almond (24ga)
Sierra Tan (24ga)
Buckskin (24ga)
Medium Bronze (24ga)
Mansard Brown (24ga)
Dark Bronze (24ga)
Dove Gray (24ga)
Slate Gray (24ga)
Charcoal Gray (24ga)
Matte Black (24ga)
Hartford Green (24ga)
Forest Green (24ga)
Hemlock (24ga)
Patina Green (24ga)
Aged Copper (24ga)
Teal Blue (24ga)
Colonial Red (24ga)
Terra Cotta (24ga)
Brilliance Red (24ga, Premium)
Burgundy (24ga)
Deep Blue Sea (24ga)
Pacific Blue (24ga)
Slate Blue (24ga)
Champagne (24ga, Premium)
Metallic Copper (24ga, Premium)
Preweathered Galvalume (24ga, Premium)
Bright Silver (24ga, Premium)

Painted BBM Board & Batten® finishes are Energy Star rated, reflecting 25-67% of the sun’s rays.
Available colors vary by branch and gauge. Color accuracy is limited by scanning and viewing conditions.
Actual samples available on request.


Primarily PDF downloads, these resources provide general, installation, and testing data.

Energy Star®

BBM Board & Batten finishes reflect 25-67% of the sun’s rays, though siding systems have no Energy Star® label.
